Compressor Endurance Test Stand

Product Overview:

LINK’s Compressor Endurance Test Stands are built based on your specific needs, and are configured to control parameters such as compressor speed, compressor ambient temperature, clutch cycling, evaporator heat load, discharge pressure, suction pressure, etc. Designed for quick compressor changeout and reliability, count on our test stands when you perform warranty audits, quality control, life cycle testing, and mounting force determination testing.

Key Benefits:

These stands are designed for quick compressor changeout and reliability of operation
Semi-automatic controls (PID control loops) with connections to dataloggers
Fully automated data acquisition and control systems

Applications and Test Types:

Warranty audits
Quality control
Life cycle (endurance) testing
Mounting force determination testing

Custom specifications are available upon request
